IFL-30P-LM-L  30W Smart Pulse Fiber Laser
IFL-30P-LM-L Smart Fiber Laser ( L-series) is design with integrated cooling and iLuma's unique SRS suppression technology. Based on MOPA technology, Smart Fiber Laser gives 1mJ pulse energy with the maximum peak power over 20KW. Without the waveform selection, the pulse width is automatically reduced from 350ns in repetition rate of 20KHz down to 10s ns in repetition rate of over 200KHz so that the optimized peak power can be given over the operation range. This features makes the L series fiber laser the choice laser source for normal metal marking, plastic marking, resistor triming and anodised Al black marking.

Features
√   Same Interface with Q-Switch Fiber Laser
√   Peak power up to 20 KW
√   Operation Range from 1 kHz to 800 kHz
√   Automatic Waveform Selection with Rep Rates
√   Beam Quality M² < 2
√  Max. Pulse Energy > 1 mJ
√   Peak Power at 200 kHz > 10 KW
√   2 years Warranty
√   Optimised Peak Power over all Rep Rates
√   Integrated Isolator with Beam Delivery Optics

√   SCSI  Hardware and RS-232 Software Control

√   Real time monitoring & Shutdown Protection
Applications
√   Metal Marking, Color Marking
√   Black Marking on Anodized Al
√   Ceramic Marking, hole drilling
√   Poly-compounds Marking
√   IC Marking
√   Ceramic Scribing and Cutting
√   Mono silicon, Poly silicon Processing
√   Resistor Trimming
√   Solar Cell Scribing
√   ITO Film removal
√   Hole drilling

*Single Shot and pulses on demand available
